Descripción
This original Einhell electronic flow switch is ideally suited for retrofitting into garden pumps within domestic water dispensers. It is responsible for turning on and off the pumps for water extraction. Electronic pressure flow switch ensures perfect pressure ratios.
If the faucet is opened and the pressure drops in the line, then it automatically turns on the pump. As soon as the tap is closed, the pressure increases and the pump turns off automatically. Using the connection adapter, this practical additional equipment can be connected to pumps. In addition, it has a plug and a 1.45 m network line. The flow switch is equipped with a check valve and dry run protection and is suitable for max. working pressure of 10 bar.
CHARACTERISTICS
- For retrofitting garden pumps into domestic water dispensers
- Enables automatic connection and disconnection of garden pumps
- Retention valve
- Dry running protection
- connection adapter
- Integrated socket
- 1.45 meter network cable
SPECIFICATIONS
- Mains supply: 230 V | 50Hz
- Max current: 10A
- Max. Operational pressure: 10 bar
- Max. temperature of water: 55 °C
- Suction side connection: 33.3 mm (R1 AG)
- Suction side connection thread material: brass
- Power cord: 145cm | H07RN-F
